PON SFP transceiver meets the the requirements of FTTx network to accelerate the speed or capacity. PON OLT, ONU and ONT SFP module have their respective roles to play in the GPON and EPON networks.
XGPON ONU STICK
| Part Number | Model No. | Picture | Data Rate(Mbps) | Wavelength | Media Type | Reach | TX Power(dBm) | RX Sens.(dBm) | Temp.(℃) | Note | Datasheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
| ST-GPON-ONU-STICK-B+ | GPON-ONU-STICK-B+ |  |
1.25GTx~2.5GRx | 1310Tx/1490Rx | Simplex SC/APC | 20km | +0.5~+5dBm | -28dBm | 0°C~70°C | GPON ONU STICK SMF | |
| ST-GPON-ONU-STICK-B+I | GPON-ONU-STICK-B+I | |
1.25GTx~2.5GRx | 1310Tx/1490Rx | Simplex SC/APC | 20km | +0.5~+5dBm | -28dBm | -40°C~+85°C | GPON ONU STICK SMF | |
| ST-XGPON-ONU-20 | XGPON-ONU-20 |  |
2.5GTx~10GRx | 1270Tx/1577Rx | Simplex SC/UPC | 20km | +2~+7dBm | -28dBm | 0°C~70°C -40°C~+85°C | ONU (ODN:N1 or N2a class) | |
| ST-XGS-PON-ONU-20 | XGS-PON-ONU-20 | |
10GTx~10GRx | 1270Tx/1577Rx | Simplex SC/UPC | 20km | +5~+9dBm | -29dBm | 0°C~70°C | XGS-PON | |
| ST-XGS-PON-ONU-20I | XGS-PON-ONU-20I | |
10GTx~10GRx | 1270Tx/1577Rx | Simplex SC/UPC | 20km | +4~+9dBm | -28dBm | -40°C~+85°C | XGS-PON |
