Sate Optics’s 200G QSFP56 Transceiver series includes QSFP56 SR4, QSFP56 FR4, QSFP56 LR4, QSFP56 PSM8 and QSFP56 ER4.
Sate Optics also provides 200G QSFP56 DAC and 200G QSFP56 AOC products.
200G QSFP56 Transceivers
| Part Number | Model No. | Picture | Data Rate(Mbps) | Wavelength | Media Type | Reach | TX Power(dBm) | RX Sens.(dBm) | Temp.(℃) | Note | Datasheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
| ST-200G-QSFP56-SR4 | 200G-QSFP56-SR4 |  |
200G | 850nm VCSEL | MPO-12 | 100m | -6.5~+4dBm | -8.4dBm | 0°C~70°C | MMF | |
| ST-200G-QSFPDD-SR8 | 200G-QSFPDD-SR8 | |
200G | 850nm | MPO-16 | 100m | -8.4~+2.4dBm | -10.3dBm | 0°C~70°C | MMF | |
| ST-200G-QSFP56-PSM8 | 200G-QSFP56-PSM8 |  |
200G | 1310nm | MPO | 2km | -2.9~+4dBm | -12.66dBm | 0°C~70°C | SMF | |
| ST-200G-QSFP56-FR4 | 200G-QSFP56-FR4 |  |
200G | 1310nm | Duplex LC | 2km | -4.2~+4.7dBm | -8.2dBm | 0°C~70°C | SMF | |
| ST-200G-QSFP56-LR4 | 200G-QSFP56-LR4 |  |
200G | 1310nm | Duplex LC | 10km | -4~+2dBm | -12.66dBm | 0°C~70°C | SMF | |
| ST-200G-QSFP56-ER4 | 200G-QSFP56-ER4 |  |
200G | 1310nm | Duplex LC | 40km | +0.4~+6.6dBm | -10.3dBm | 0°C~70°C | SMF |
