The 100G QSFP28 transceiver series include different form factors such as QSFP28 and CFP4.
Sate Optics’s 100G QSFP28 Transceiver series includes QSFP28-SR4, QSFP28-LR4, QSFP28-ER4, QSFP28-ZR4, QSFP28-BIDI, QSFP28-PSM4 and QSFP28-CWDM4.
It offers connecting solution from 100m to 40km for data centers, high speed network and 5G.
The name of the 100G QSFP28 comes from the fact that its electrical interface can handle four channels of 25G each, potentially up to 28G. Sate Optics also provides 100G QSFP28 DAC and 100G QSFP28 AOC products.
100G QSFP28 Transceivers
| Part Number | Model No. | Picture | Data Rate(Mbps) | Wavelength | Media Type | Reach | TX Power(dBm) | RX Sens.(dBm) | Temp.(℃) | Note | Datasheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
| ST-100G-QSFP28-SR4 | 100G-QSFP28-SR4 |  |
100G | 850nm | MTP/MPO | 100m | -8.4~+2.4dBm | -10.3dBm | 0°C~70°C | MMF | |
| ST-100G-QSFP28-SR-BD | 100G-QSFP28-SR-BD |  |
100G | 850nm/900nm | Dual LC | 100m | -6.2~+4dBm | -8.2dBm | 0°C~70°C | MMF | |
| ST-100G-QSFP28-CWDM4-2 | 100G-QSFP28-CWDM4-2 |  |
100G | 1271nm~1331nm | Duplex LC | 2km | -6.5~+2.5dBm | -10dBm | 0°C~70°C | SMF | |
| ST-100G-QSFP28-CWDM4 | 100G-QSFP28-CWDM4 |  |
100G | 1271nm~1331nm | Duplex LC | 10km | -6.5~+2.5dBm | -13dBm | 0°C~70°C | SMF | |
| ST-100G-QSFP28-PSM4-2 | 100G-QSFP28-PSM4-2 |  |
100G | 4*1310nm | MTP/MPO | 2km | -6~+2dBm | -11.35dBm | 0°C~70°C | SMF | |
| ST-100G-QSFP28-PSM4 | 100G-QSFP28-PSM4 |  |
100G | 4*1310nm | MPO | 10km | -6~+2dBm | -12dBm | 0°C~70°C | SMF | |
| ST-100G-QSFP28-LR4 | 100G-QSFP28-LR4 |  |
100G | 1295/1300/1304/1309nm | Duplex LC | 10km | -4.3~+4.5dBm | -10.6dBm | 0°C~70°C | SMF | |
| ST-100G-QSFP28-LR4-I | 100G-QSFP28-LR4-I |  |
100G | 1295/1300/1304/1309nm | Duplex LC | 10km | -4.3~+4.5dBm | -10.6dBm | -40°C~85°C | SMF | |
| ST-100G-QSFP28-LR4-20 | 100G-QSFP28-LR4-20 |  |
100G | 1295/1300/1304/1309nm | Duplex LC | 20km | -4.3~+4.5dBm | -10.6dBm | 0°C~70°C | SMF | |
| ST-100G-QSFP28-ER4 | 100G-QSFP28-ER4 |  |
100G | 1295/1300/1304/1309nm | Duplex LC | 30km/40km | -2.5~+6.5dBm | -18.5dBm | 0°C~70°C | SMF | |
| ST-100G-QSFP28-ZR4 | 100G-QSFP28-ZR4 |  |
100G | 1295/1300/1304/1309nm | Duplex LC | 80km | +1.5~+7dBm | -28dBm | 0°C~70°C | SMF | |
| ST-100G-QSFP28-ZR4+ | 100G-QSFP28-ZR4+ |  |
100G | 1295/1300/1304/1309nm | Duplex LC | 100km | +4~+7.5dBm | -30dBm | 0°C~70°C | SMF |
100G QSFP28 SINGLE LAMBDA Transceivers
| Part Number | Model No. | Picture | Data Rate(Mbps) | Wavelength | Media Type | Reach | TX Power(dBm) | RX Sens.(dBm) | Temp.(℃) | Note | Datasheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
| ST-100G-QSFP28-DR1 | 100G-QSFP28-DR1 |  |
100G | 1310nm | Duplex LC | 500m | -2.9~+4dBm | -5.9dBm | 0°C~70°C | SMF | |
| ST-100G-QSFP28-FR1 | 100G-QSFP28-FR1 |  |
100G | 1310nm | Duplex LC | 2km | -3.1~+4dBm | -7.1dBm | 0°C~70°C | SMF | |
| ST-100G-QSFP28-LR1 | 100G-QSFP28-LR1 |  |
100G | 1310nm | Duplex LC | 10cm | -2.4~+4.5dBm | -7.7dBm | 0°C~70°C | SMF |
100G QSFP28 BIDI Transceivers
| Part Number | Model No. | Picture | Data Rate(Mbps) | Wavelength | Media Type | Reach | TX Power(dBm) | RX Sens.(dBm) | Temp.(℃) | Note | Datasheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
| ST-100G-QSFP28-BD-10D/U | 100G-QSFP28-BD-10D/U |  |
100G | Tx1271/Rx1331 Tx1331/Rx1271 | Simplex LC | 10km | -1.4~+4.5dBm | -7.7dBm | 0°C~70°C | SMF | |
| ST-100G-QSFP28-BD-20D/U | 100G-QSFP28-BD-20D/U |  |
100G | Tx1271/Rx1331 Tx1331/Rx1271 | Simplex LC | 20km | -1.4~+4.5dBm | -7.7dBm | 0°C~70°C | SMF | |
| ST-100G-QSFP28-BD-30DU | 100G-QSFP28-BD-30DU |  |
100G | Tx13xx/Rx13xx | Simplex LC | 30km | 0~+5.6dBm | -14.7dBm | 0°C~70°C | SMF |
100G QSFP28 DWDM Transceivers
| Part Number | Model No. | Picture | Data Rate(Mbps) | Wavelength | Media Type | Reach | TX Power(dBm) | RX Sens.(dBm) | Temp.(℃) | Note | Datasheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
| ST-100G-PAM4-DWDM-80 | 100G-PAM4-DWDM-80 |  |
100G | C13~C60+ | Dual CS | 80km | -1 ~ +4dBm | -12.5dBm | 0°C~70°C | SMF |
100G CFP Transceivers
| Part Number | Model No. | Picture | Data Rate(Mbps) | Wavelength | Media Type | Reach | TX Power(dBm) | RX Sens.(dBm) | Temp.(℃) | Note | Datasheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
| ST-100G-CFP-ER4 | 100G-CFP-ER4 |  |
100G | 1295nm~1309nm | Duplex LC | 40km | -2.9~+2.9dBm | -20.9dBm | 0°C~70°C | SMF | |
| ST-100G-CFP-LR4 | 100G-CFP-LR4 |  |
100G | 1295nm~1309nm | Duplex LC | 10km | -4.3~+4.5dBm | -10.6dBm | 0°C~70°C | SMF |
100G CFP2 Transceivers
| Part Number | Model No. | Picture | Data Rate(Mbps) | Wavelength | Media Type | Reach | TX Power(dBm) | RX Sens.(dBm) | Temp.(℃) | Note | Datasheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
| ST-100G-CFP2-LR4 | 100G-CFP2-LR4 |  |
100G | 1294nm~1310nm | Duplex LC | 10km | -4.3~+4.5dBm | -10.6dBm | 0°C~70°C | SMF | |
| ST-100G-CFP2-ER4 | 100G-CFP2-ER4 |  |
100G | 1294nm~1310nm | Duplex LC | 40km | -2.9~+2.9dBm | -20.9dBm | -5°C~70°C | SMF |
100G CFP4 Transceivers
| Part Number | Model No. | Picture | Data Rate(Mbps) | Wavelength | Media Type | Reach | TX Power(dBm) | RX Sens.(dBm) | Temp.(℃) | Note | Datasheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
| ST-100G-CFP4-LR4 | 100G-CFP4-LR4 |  |
100G | 1294nm~1310nm | Duplex LC | 10km | -4.3~+4.5dBm | -10.6dBm | 0°C~70°C | SMF |
